| Yamaha FZ-X Hybrid STD General Features | |
|---|---|
| Engine Type | Air cooled, 4-stroke, SOHC, 2-valve |
| Top Speed | - |
| Engine Capacity | - |
| Starting | - |
| Brakes | Double Disc |
| Gear Box | 5 Speed |
| Fuel Tank Capacity | 10 L |
| Tyre Type | Tubeless |
| Yamaha FZ-X Hybrid STD Standard Features | |
|---|---|
| Brakes | Double Disc |
| Pass Switch | |
| Cooling System | - |
| ABS | Single Channel |
| CBS | - |
| Ebs | - |
| Body Graphics | - |
| Carry Hook | - |
| Shutter Lock | - |
| Yamaha FZ-X Hybrid STD Engine & performance | |
|---|---|
| Engine Type |
Air cooled, 4-stroke, SOHC, 2-valve
|
| Displacement |
149
|
| Mileage |
-
|
| Bore |
57.3 mm
|
| Stroke |
57.9 mm
|
| Compression Ratio |
9.6 : 1
|
| Maximum Power |
12.4 PS @ 7250 rpm
|
| Maximum Torque |
13.3 Nm @ 5500 rpm
|
| Starting |
Self Start Only
|
| Maximum Speed |
-
|
| Yamaha FZ-X Hybrid STD Transmission | |
|---|---|
| Gear Box |
5 Speed
|
| Clutch |
Wet, Multiple-disc
|
| Transmission Type |
Manual
|
| Yamaha FZ-X Hybrid STD Fuel | |
|---|---|
| Fuel Capacity |
10 L
|
| Supply System |
-
|
| Fuel Reserve |
1.6 L
|
| Fuel Gauge |
Digital
|
| Digital Fuel Gauge |
-
|
| Yamaha FZ-X Hybrid STD Brake | |
|---|---|
| Brakes |
Double Disc
|
| Front Brake |
Disc
|
| Rear Brake |
Disc
|
| Yamaha FZ-X Hybrid STD Tyre Size | |
|---|---|
| Tyre Size |
Front :-100/80-17 Rear :-140/60-17 |
| Radial Tyres |
-
|
| Yamaha FZ-X Hybrid STD Wheel Size | |
|---|---|
| Wheel Size |
Front :-431.8 mm, Rear :-431.8 mm |
| Wheel Base |
1330 mm
|
| Yamaha FZ-X Hybrid STD Chassis and Suspension | |
|---|---|
| Bike Suspension |
-
|
| Yamaha FZ-X Hybrid STD Frame | |
|---|---|
| Chassis/Frame |
-
|
| Yamaha FZ-X Hybrid STD Electrical | |
|---|---|
| Ignition |
TCI (Transistor Controlled Ignition)
|
| Battery Type |
-
|
| Head Lamp |
-
|
| Tail Lamp |
-
|
| Turn Signal Lamp |
LED
|
| Yamaha FZ-X Hybrid STD Exterior Dimensions | |
|---|---|
| Length | 2020 mm |
| Height | 1100 mm |
| Width | 785 mm |
| Ground_Clearance | 165 mm |
| Saddle_Height | 810 mm |
| Kerb Weight | 141 kg |
| Total Weight | - |
| Weight_Carrying_Capacity | - |
| Chassis/Frame | - |
| Wheel Base | 1330 mm |
