| Yamaha R15S STD General Features | |
|---|---|
| Engine Type | Liquid-cooled, 4-stroke, SOHC, 4-valve |
| Top Speed | - |
| Engine Capacity | - |
| Starting | - |
| Brakes | Double Disc |
| Gear Box | 6 Speed |
| Fuel Tank Capacity | 11 L |
| Tyre Type | Tubeless |
| Yamaha R15S STD Standard Features | |
|---|---|
| Brakes | Double Disc |
| Pass Switch | |
| Cooling System | - |
| ABS | Dual Channel |
| CBS | - |
| Ebs | - |
| Body Graphics | Y |
| Carry Hook | - |
| Shutter Lock | - |
| Yamaha R15S STD Engine & performance | |
|---|---|
| Engine Type |
Liquid-cooled, 4-stroke, SOHC, 4-valve
|
| Displacement |
155
|
| Mileage |
-
|
| Bore |
58 mm
|
| Stroke |
58.7 mm
|
| Compression Ratio |
11.6:1
|
| Maximum Power |
18.4 PS @ 10000 rpm
|
| Maximum Torque |
14.2 Nm @ 7500 rpm
|
| Starting |
Self Start Only
|
| Maximum Speed |
-
|
| Yamaha R15S STD Transmission | |
|---|---|
| Gear Box |
6 Speed
|
| Clutch |
Wet, Multiple Disc
|
| Transmission Type |
Manual
|
| Yamaha R15S STD Fuel | |
|---|---|
| Fuel Capacity |
11 L
|
| Supply System |
-
|
| Fuel Reserve |
2.2 L
|
| Fuel Gauge |
Digital
|
| Digital Fuel Gauge |
-
|
| Yamaha R15S STD Brake | |
|---|---|
| Brakes |
Double Disc
|
| Front Brake |
Disc
|
| Rear Brake |
Disc
|
| Yamaha R15S STD Tyre Size | |
|---|---|
| Tyre Size |
Front :-100/80-17 Rear :-140/70-17 |
| Radial Tyres |
-
|
| Yamaha R15S STD Wheel Size | |
|---|---|
| Wheel Size |
Front :-431.8 mm, Rear :-431.8 mm |
| Wheel Base |
1325 mm
|
| Yamaha R15S STD Chassis and Suspension | |
|---|---|
| Bike Suspension |
-
|
| Yamaha R15S STD Frame | |
|---|---|
| Chassis/Frame |
-
|
| Yamaha R15S STD Electrical | |
|---|---|
| Ignition |
TCI (Transistor controlled ignition)
|
| Battery Type |
-
|
| Head Lamp |
-
|
| Tail Lamp |
-
|
| Turn Signal Lamp |
LED
|
| Yamaha R15S STD Exterior Dimensions | |
|---|---|
| Length | 1990 mm |
| Height | 1135 mm |
| Width | 725 mm |
| Ground_Clearance | 170 mm |
| Saddle_Height | 815 mm |
| Kerb Weight | 142 kg |
| Total Weight | - |
| Weight_Carrying_Capacity | - |
| Chassis/Frame | - |
| Wheel Base | 1325 mm |
